3005 Aluminum Strip| Aluminium Strip 3005

MOQ:2 to 5MT
Port:Shanghai,Qing Dao, China
Payment Terms:L/C,TT,CAD
Delivry Time:15 to 30days

Gallery

Details

Description of 3005 Aluminum Strip

Alloy 3005 is a non-heat treatable wrought alloy used in many applications. It may be work hardened or used in the annealed state for drawn parts, bending, and many forming applications. 3005 aluminium strip be widely used to produce color coated aluminum strip. Such as 3005H18; 3005H16; 3005H14; 3005H24，3005-O; Also named Pre-Coat Aluminum Coil strip. It’s will use spray cleaning, double baking and double coating, more times baking and more times coating arts and crafts process usually. The color coated aluminum can be produce for color aluminum, The color draws the aluminum plank, The roller coating aluminum, The roller coating aluminum plank, other color coating metal plank, aluminum composite panel, aluminum panel, aluminum honeycomb panel.

Detailed Specifications of 3005 Aluminium Strip

1. Alloy: 3005
2. Thickness: 0.21-8.0mm
3. Width: 16-1600mm
4. Temper: H16, H12, H24 etc
5. Minimum order quantity: 2ton
6. Package: seaworthy package.
7. Surface quality: Smooth, clean, be free of oil, stain, scratch, wave and corrosion, ready for paint, oxidation and lamination.
8. Delivery time: within 20days .
9. Usage: Mobile e battery shell; Air-conditioning; Fridge; Automotive chassis; building material; color coating; Kitchen utensils; storage device on food and chemical products; slot, tank, pressure vessel for transportation of liquid product, and pipeline; Heat sink; Makeup board; Photocopying machine drum; boat material etc.

Application of 3005 Aluminium Strip

Our aluminum coil strip widely used in various applications such as refrigerator, commercial freezer, cable wrap, capacitors, PP cap, anti-theft strip, aluminum/plastic composite pipes, PS substrated etc.
1) Radiator
2) Condenser
3) Insulation Material
4) Construction
5) Aircraft
6) Beverage cans

Chemical Properties - 3005 Aluminium Coil Strip

Alloy Designation		Si	Fe	Cu	Mn	Mg	Cr	Ni	Zn	Ti	Ga	V	Remarks	Others		Aluminium min
Numerical	Chemical Sympols													Each	Total
3005	AI Mn1Mg 0.5	0.6	0.7	0.3	1.0-1.5	0.2-0.6	0.10	-	0.25	0.10	-	-	-	0.05	0.15	Remainder

Thickness(mm)	Width(mm)	Length(mm)	ID(mm)	OD(mm)
0.2-8	≤2300	≤12000	76	≤2800
			150
			300
			505
