1050 Aluminum Strip | Aluminium Strip 1050
- MOQ:2 to 5MT
- Port:Shanghai,Qing Dao, China
- Payment Terms:L/C,TT,CAD
- Delivry Time:15 to 30days
Gallery
-
Details
Description of 1050 Aluminum Strip
Alloy:1050,1050ATemper:HO,H12,H14,H16,H18,H22,H24,H26
Thickness:0.2mm-6.0mm
Width:80mm-2300mm
MOQ:5 tons per size
Mother coil:DC or CC
ID:76mm,152mm,408mm,508mm S
urface:Mill finishing,mirror finishing,checkered
Package:Export standard package with wooden pallet
Package way:Eye to sky or eye to wall
Delivery time:within 30days
Origin:Zhengzhou,China
Features of 1050 Aluminium Strip
1. Environmental2. Light weight
3. Waterproof
4. Anti-rust
5. Weather resistance
6. Easy cleaning
7. Easy matching with other decoration material
Application of 1050 Aluminium Strip
1.Lighting, printing, packing, decorative, electronics surface, hot rolled thick plate, PS base plate, aluminium plastic base plate, aluminium curtain wall base plate, aluminium composite panel base plate, aluminium spacer, aluminium embossed sheet.2.Interior:wall cladding,ceilings,bothrooms,kitchens and balconies,shutters,doors,curtain wall.
3.Exterior:wall cladding,facades,roofing,camopies,tunnels,column cover,renovations.
4.Advertisement:display platforms,signboards,fascia,shop fronts.
Chemical Properties of 1050 Aluminium Strip
| Alloy Designation | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ti | Ga | V | Remarks | Others |
Aluminium min |
||
| Numerical | Chemical Sympols | Each | Total | |||||||||||||
| 1050 | AI 99.5 | 0.24 | 0.40 | 0.05 | 0.05 | 0.05 | - | - | 0.07 | 0.05 | - | - | - | 0.03 | - | 99.50 |
TOLERANCE of 1050 Aluminium Strip
| TOLERANCE | |||||||
| Major Brand | 1050(O) | ||||||
| Thickness | 0.2-0.4 | 0.4-0.8 | 0.9-1.1 | 1.2-1.6 | 1.8-2.0 | ||
| tolerance | ±0.01 | ±0.015 | ±0.02 | ±0.025 | ±0.03 | ||
| Width | <100 | 100-200 | 201-500 | 501-1250 | >1250 | ||
| tolerance | ±0.1 | ±0.2 | ±0.2 | ±1 | ±2 | ||
| BURR AND COLLAPSE | |||||||
| The width of aluminum belt | burr’s height | collapsed side’s height | |||||
| <0.2 | 0.01 | ≥0.05-0.1 | |||||
| 0.2-1.0 | 0.015 | ||||||
| 1.1-1.5 | 0.02 | ||||||
| >1.6 | 0.03 | ||||||
| MECHANICAL PROPERTY | |||||||
| U.T.S: 60-95N/mm2 | Elongation: >25% | ||||||
| Density in 20°C :2.703kg/dm3 | Max.resistance in 20°C:≤0.02825Ωmm2/m | ||||||
